SPECIFICATION
Rated Power	3200 VA
AC Input
AC Input	230 VAC
Voltage	170~280 VAC (For Personal Computer)
Selectable Voltage Range	90~280VAC (For Home Appliances)
Frequency Range	-
AC OUTPUT
AC output	50 HZ / 60 HZ (Auto Sensing)
AC Voltage Regulation	230 VAC + 5%
Surge Power	6000 VA
Efficiency (Peak) PV to INV	97%
Efficiency (Peak) Battery to Inv	94%
Transfer Time	10 ms (For Personal Computers); 20 ms (For Home Appliances)
BATTERY AND AC CHARGER
Battery Voltage	24 VDC
Floating Charge Voltage	27 VDC
Overcharge Protection	33VDC
Maximum AC Charge Current	60A
SOLAR CHARGER
Maximum PV Array Power	4200W
MPPT Range @ Operating Voltage	120-430 VDC
Maximum PV Array Open Circuit Voltage	500 VDC
Maximum Charge Current	TRUE (MPPT) 100A
Maximum PV Input Current	18A
Maximum Efficieny	98%
PHYSICAL
Communication Interface	RS323/GPRS/Wi-Fi
OPERATING ENVIRONMNET
Humidity	5% to 95% Relative Humidity (Non~Condensing)
Operating Temperature	0°C~55°C
Storage Temperature	-15°C-~60°C
