Description

• Introducing 1st time in Pakistan, Supporting 600W Plus solar panels in small size inverter
• 100% Pure Sine Wave Solar Inverter
• Built-in (100A) MPPT Solar Charge Controller
• Wi-Fi Optional - available for IOS/Android Built-in anti dust for harsh environment
• Smart battery charger design to optimize battery life
• Inverter running with battery & with-out battery
• Compatible with Li-ion, LifePo4 and etc
• High input voltage range (120~430VDC) for easy sharing with load
• Adaptable to main voltage/generator power
• Conformal coating to prevent from Dust & Humidity
• Design and Engineered in Taiwan

  Rated Power	1700VA
  AC Input
  Voltage	230 VAC
  Selectable Voltage Range	170~280 VAC (For Personal Computer)
  Frequency Range	90~280VAC (For Home Appliances)
  AC OUTPUT
  AC Output	50 HZ / 60 HZ (Auto Sensing)
  AC Voltage Regulation	230 VAC + 5%
  Surge Power	3000 VA
  Efficiency (Peak) PV to INV	97%
  Efficiency (Peak) Battery to Inv	94%
  Transfer Time	10 ms (For Personal Computers); 20 ms (For Home Appliances)
  BATTERY AND AC CHARGER
  Battery Voltage	12 VDC
  Floating Charge Voltage	14 VDC
  Overcharge Protection	16 VDC
  Maximum AC Charge Current	60A
  SOLAR CHARGER
  Maximum PV Array Power	2500W
  MPPT Range @ Operating Voltage	120-430 VDC
  Maximum PV Array Open Circuit Voltage	500 VDC
  Maximum Charge Current	TRUE (MPPT) 100A
  Maximum PV Input Current	18A
  Maximum Efficieny	98%
  PHYSICAL
  Communication Interface	RS323/GPRS/Wi-Fi
  OPERATING ENVIRONMNET
  Humidity	5% to 95% Relative Humidity (Non~Condensing)
  Operating Temperature	0°C~55°C
  Storage Temperature	-15°C-~60°C
