Model No. | PLC-325P-IR2/PR |
---|---|
Imaging Device | 1/2.7" Progressive CMOS |
Total Pixels | 2608ï¼Hï¼Ã1960ï¼Vï¼ |
Effective Pixels | 2608ï¼Hï¼Ã1960ï¼Vï¼ |
Scanning System | Internal |
Min. Illumination | 0.05lux@F1.2 (AGC ON),0Lux with IR ON |
Video Output | BNC |
Resolution | 5MP 2592ï¼Hï¼Ã1944ï¼Vï¼ |
Max, Framerate | 5AHD/5TVI: 5MP@20fps 4AHD/4CVI/4TVI: P@25fps N@30fps CVBS: 960H |
Focal Length (Zoom Ratio) | 3.6mm |
Max. Aperture Ratio | F2.2 |
Angular Field of View | H:91.3° / V:46.1° / D:109.6° |
Min. Object Distance | 0.8m |
Lens Type | Fixed lens |
Audio | Audio over coaxial |
Audio Range | N/A |
IR Distance | 20m |
On Screen Display | English |
Day & Night | Auto / Ext / Colour / B/W |
Backlight Compensation | Off / User BLC |
Wide Dynamic Range | N/A |
Digital Noise Reduction | 2D DNR |
Gain Control | Auto |
White Balance | ATW |
Electronic Shutter Speed | Auto |
Reverse | Mirror |
Remote control interface | ACP (AHD Coax Protocol) |
Video Transmission Distance | MAX 300M ï¼ Cable: 5C 2Vï¼ |
Operating Temperature / Humidity | -30°C ~ 50°C / 90% |
Ingress Protection | IP66 |
Input Voltage/Current | 12V DC |
Power Consumption | IR OFF â¤1Wï¼IR ON â¤4W |
Colour / Material | White / plastic |
Weight | 380 g |
Safety | CE LVD |
EMC | CE EMCãFCC |
ROHS | RoHS2.0 |
