B560M-A PRO

M.2 SHIELD FROZR:

Worldâ€™s fastest SSDs can start to lower performance when getting hot. Part of the motherboards heatsink design, M.2 SHIELD FROZR is the next generation M.2 thermal solution to avoid this by offering the best thermal protection to make sure that SSD maintains maximum performance.

FROZR AI COOLING:

Detecting CPU & GPU temperatures and automatically adjusting fan duty of system fans to a proper value by adopting MSI AI ENGINE.

FULLY CONTROLLABLE IN BIOS AND SOFTWARE:

MSI motherboards let you manage speeds and temperatures for all your system and CPU fans. Total Fan Control allows you check your primary system characteristics in a simplified graphical interface. You can also set up to 4 temperature targets for CPU and motherboard, which will adjust the fan speeds automatically.

HIGH-BANDWIDTH AND LOW-LATENCY NETWORK:

2.5Gbps LAN provides incredible data transfer speed faster than general Gigabit LAN. This is a premium solution for demanding users.

A HUGE STEP OF DDR PERFORMANCE:

MSI OC LAB does not merely work hard on extreme overclocking. Compare to B460 motherboard memory XMP profile, MSI does have great improvement on performance and efficiency for B560. Easy to enable XMP profile with auto power settings to get the best memory speed and stability.

CORE BOOST:

Core Boost technology combines MSI's premium layout and optimized power design which allows for faster and undistorted current delivery to the CPU at pin-point precision. Not only supporting multi-core CPU, also creating the perfect conditions for your CPU overclocking.

Specifications:

CPU:

Chipset	Intel B560
CPU Socket	LGA 1200

Back Panel I/O:

USB	2 x USB 2.0 Type-A 4 x USB 3.1 / USB 3.2 Gen 1 Type-A
Thunderbolt	None
Display	1 x HDMI 2.0b 1 x VGA
Audio	3 x 3.5 mm
Ethernet / Controller	1 x Realtek 8125B 2.5Gigabit
PS/2	1 x Combo

Memory:

Memory Slots	2 x 288-Pin
Memory Support	DDR4 2133, 2666, 2933, 3200, 4700, 5200 MHz
Maximum Capacity	64 GB
Channel Architecture	Dual Channel
ECC Support	Non-ECC Unbuffered

Storage Expansion:

SATA	6 x SATA III
M.2	1 x M Key 2242, 2260, 2280 (PCIe 4.0 x4, PCIe 3.0 x4, SATA III)
U.2	None
Optane Memory Support	Yes

Internal I/O:

Expansion Slots	1 x PCIe 4.0 x16 2 x PCIe 3.0 x1
USB	1 x USB 3.1 / USB 3.2 Gen 1 Header (Supports 2 USB Type-A Port) 2 x USB 2.0 Header (Supports 4 USB Type-A Port)
Air Cooling	1 x 4-Pin CPU 2 x 4-Pin System
Power Connectors	1 x 24-Pin Mainboard 1 x 8-Pin ATX
Security	Chassis Intrusion, TPM Module
Audio	1 x Speaker
Diagnostics	Clear CMOS
Legacy	1 x Serial
