• Capacity (Ton): 4 Ton
• Refrigerant: R22
• Color: White
• Capacity
• Cooling Capacity KW: 14
• Cooling Capacity (BTU): 48000
• Heating Capacity (BTU): 51100
• Air Circulation (M3/H): 1750
• Rated Power Input (KW) Cooling: 5.25
• Rated Power Input (KW) Heating: 5.23
• Power Supply (Ph/V/Hz): 3/380-415/50
• EER/COP(W/W): 2.67/2.87

Piping Connection

• Gas Side Dia (Mm): 19.05
• Liquid Side Dia (Mm): 9.52
• Max Pipe Length (M): 50
• Max Drop (M): 15

Dimensions

• Indoor Net Dimension W/D/H: 530/380/1820
• Indoor Packing Dimension W/D/H: 625/465/1965
• Outdoor Net Dimension W/D/H: 1008/410/830
• Outdoor Packing Dimension W/D/H: 1130/490/930
• Panel Net Dimension W/D/H:
• Panel Packing Dimension W/D/H:

Noise

• Indoor Noise [Db(A)] (Hi/Mid/Lo): 49/46/42
• Outdoor Noise [Db(A)]: 59
