Description

Product Specifications

Camera:-

Sensor: 1/2.8 inches, CMOS, Effective Pixel: 2.07M
Scanning Mode: Progressive
Type of Lens Mount: M12
Lens I:   Focus: f-2.8mm, Horizontal FOV:90°
AF: Support TOF
Minimum IlluminationNR: 0.5 Lux@ (F2.0, AGC ON)
Shutter: 1/30s 1/10000s
White Balance: Auto, Manual, VAR
Camera Stand: Standard Damped Rotary Support
Physical Privacy Security:  Support
Digital Noise Reduction: 2D & 3D Digital Noise Reduction
Backlight Compensation: Support
Digital Zoom: Support

Interface:-

USB Interface:  1 x USB 2.0,Type-C;

Audio Features:-

Audio: 3A Algorithm Support AEC/AGC/ANS
IR Remote Control:  82 dB SPL at 0.5 m
Microphone: Omnidirectional Microphone, Sensitivity: â€“ 30±2dB

Operating System Supported:
Windows® 7 (only 1080P and below supported), Windows 8.1, Windows 10 or higher macOS ™ 10.10 or
higher Google â„¢ Chromebook â„¢ Version 29.0.1547.70 or higher Linux (support UVC)
Hardware Requirements: 2.4 GHz Intel® Core 2 Duo CPU or
higher 2 GB RAM or more USB 2.0 interface
Signal System:  1080p/30/25, 720p/30/25, 960 x 540p/30/25, 640 x 360p/30/25
Color System/Compression: YUY2 / H.264 / MJPEG
USB Video Communication Protocol: UVC 1.1
UAC:  Support
UVC PTZ Control:  Support (EPTZ)

General Specifications:-

Input Voltage: 5 V (USB Power Supply)
Power Consumption: 2.5W (Max.)
Dimensions: 121mm x 32mm x 31mm (Bracket not included)
Net Weight: 139g
Input Current: 0.5 A
Operating Temperature: 0 ~ 40° C
Storage Temperature: -40° C ~ 60° C
