Type

22.3 x 14.9mm CMOS

Effective Pixels

Approx. 18.0 megapixels

Total Pixels

Approx. 18.5 megapixels

Aspect Ratio

3:2

Low-Pass Filter

Built-in/Fixed

Sensor Cleaning

EOS integrated cleaning system

Colour Filter Type

Primary Colour

Type

DIGIC 5

Lens Mount

EF/EF-S

Focal Length

Equivalent to 1.6x the focal length of the lens

Type

TTL-CT-SIR with a CMOS sensor

AF System/ Points

9 cross-type AF points (f/2.8 at centre)

AF Working Range

EV -0.5 -18 (at 23°C & ISO100)

AF Modes

AI Focus

One Shot

AI Servo

AF Point Selection

Automatic selection, Manual selection

Selected AF Point Display

Superimposed in viewfinder and indicated on LCD monitor

Predictive AF

Yes, up to 10m¹

AF Lock

Locked when shutter button is pressed half way in One Shot AF mode.

AF Assist Beam

Intermittent firing of built-in flash or emitted by optional dedicated Speedlite

Manual Focus

Selected on lens

Metering Modes

TTL full aperture metering with 63-zone SPC

(1) Evaluative metering (linked to all AF points)

(2) Partial metering at center (approx. 9% of viewfinder)

(3) Spot metering (approx. 4% of viewfinder at center)

(4) Center weighted average metering

Metering Range

EV 1-20 (at 23°C with 50mm f/1.4 lens ISO100)

AE Lock

Auto: In One-shot AF mode with evaluative metering exposure is locked when focus is achieved.

Manual: By AE lock button in creative zone modes.

Exposure Compensation

+/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).

AEB

3 shots +/- 2 EV, 1/2 or 1/3-stop increments

ISO Sensitivity*

AUTO(100-6400), 100-12800 in 1-stop increments

ISO can be expanded to H: 25600

During Movie shooting: Auto (100-6400), 100-6400 (Whole stop increments) ISO can be expanded to H: 12800

Type

Electronically-controlled focal-plane shutter

Speed

30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)

Type

Auto white balance with the imaging sensor

Settings

AWB, Daylight, Shade, Cloudy, Tungsten, White

Fluorescent light, Flash, Custom.

White balance compensation:

1. Blue/Amber +/-9

2. Magenta/ Green +/-9.

Custom White Balance

Yes, 1 setting can be registered

WB Bracketing

+/-3 levels in single level increments

3 bracketed images per shutter release.

Selectable Blue/Amber bias or Magenta/Green bias.

Type

Pentamirror

Coverage (Vertical/Horizontal)

Approx. 95%

Magnification

Approx. 0.85x (4)

Eyepoint

Approx. 19mm (from eyepiece lens centre)

Dioptre Correction

-3 to +1 m-1 (dioptre)

Focusing Screen

Fixed

Mirror

Quick-return half mirror (Transmission: reflection ratio of 40:60, no mirror cut-off with EF600mm f/4 or shorter)

Viewfinder Information

AF information: AF points, focus confirmation light¹

Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, spot metering circle, exposure warning, AEB

Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation, red-eye reduction light

Image information: Highlight tone priority (D+), monochrome shooting, maximum burst (1 digit display), White balance correction, SD card information

Depth of Field Preview

Yes, with Depth of Field preview button.

Eyepiece Shutter

On strap

Type

Touch screen vari angle 7.7cm (3.0") 3:2 Clear View II TFT, approx. 1040K dots

Coverage

Approx. 100%

Viewing Angle (Horizontally/Vertically)

Approx. 170°

Coating

Solid Structure and Anti smudge

Brightness Adjustment

Adjustable to one of seven levels

Display Options

(1) Quick Control Screen

(2) Camera settings

Built-in Flash GN (ISO 100, meters)

13

Built-in Flash Coverage

up to 17mm focal length (35mm equivalent: 28mm)

Built-in Flash Recycle Time

Approx. 3 seconds

Modes

Auto, Manual flash, Integrated Speedlite Transmitter

Red-Eye Reduction

Yes - with red-eye reduction lamp

X-Sync

1/200sec

Flash Exposure Compensation

+/- 2EV in 1/2 or 1/3 increments

Flash Exposure Bracketing

Yes, with compatible External Flash

Flash Exposure Lock

Yes

Second Curtain Synchronisation

Yes

HotShoe/ PC Terminal

Yes/ No

External Flash Compatibility

E-TTL II with EX series Speedlites, wireless multi-flash support

External Flash Control

via camera menu screen

Modes

Scene Intelligent Auto (Stills and Movie), No Flash, Creative Auto, Portrait, Landscape, Close-up, Sports, SCN(Night Portrait, Handheld Night Scene, HDR Backlight Control), Program AE, Shutter priority AE, Aperture priority AE, Manual (Stills and Movie)

Picture Styles

Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined (x3)

Colour Space

sRGB and Adobe RGB

Drive Modes

Single, Continuous, Self timer (2s, 10s+remote, 10s + continuous shots 2-10)

Continuous Shooting

Max. Approx. 5fps. for approx. (speed maintained for approx. 22 images (JPEG)¹, 6 images (RAW))²³

Type

Electronic viewfinder with image sensor

Coverage

Approx. 99% vertically and approx.100% horizontally

Frame Rate

60 fps

Focusing

Manual Focus (Magnify the image 5x or 10x at any point on screen)

Autofocus: Hybrid CMOS AF (Face detection and Tracking AF, FlexiZone-Multi, FlexiZone-Single), Phase detection AF (Quick mode)

Metering

Real-time evaluative metering with image sensor.

Evaluative metering, partial metering, spot metering, center-weighted average metering.

Display Options

Grid overlay (x2), Histogram, Multi aspect ratios

Still Image Type

JPEG: Fine, Normal (Exif 2.30 compliant) / Design rule for Camera File system (2.0),

RAW: RAW (14bit, Canon original RAW 2nd edition),

Digital Print Order Format [DPOF] Version 1.1 compliant

RAW+JPEG Simultaneous Recording

Yes (RAW + Large JPEG only)

Image Size

JPEG 3:2: (L) 5184x3456, (M) 3456x2304, (S1) 2592x1728, (S2) 1920x1280, (S3) 720x480

JPEG 4:3: (L) 4608x3456, (M) 3072x2304, (S1) 2304x1728, (S2) 1696x1280, (S3) 640x480

JPEG 16:9: (L) 5184x2912, (M) 3456x1944, (S1) 2592x1456 (S2) 1920x1080, (S3) 720x400

JPEG 1:1: (L) 3456x3456, (M) 2304x2304, (S1) 1728x1728, (S2) 1280x1280, (S3) 480x480

RAW: (RAW) 5184x3456

Movie Type

MOV (Video: H.264, Sound: Linear PCM, recording level can be manually adjusted by user)

Movie Size

1920 x 1080 (29.97, 25, 23.976 fps)

1280 x 720 (59.94, 50 fps)

640 x 480 (30, 25 fps)

Movie Length

Max duration 29min 59sec, Max file size 4GB (If file size exceeds 4GB a new file will be created automatically)

Folders

New folders can be manually created and selected

File Numbering

(1) Consecutive numbering

(2) Auto reset

(3) Manual reset

Custom Functions

8 Custom Functions with 24 settings

Metadata Tag

User copyright information (can be set in camera)

Image rating (0-5 stars)

Intelligent Orientation Sensor

Yes

Playback Zoom

1.5x - 10x enabled in 15steps

Display Formats

(1) Single image with information (2 levels)

(2) Single image

(3) 4 image index

(4) 9 image index

(4) Jump Display (1/10/100 images, by Date,by Folder, Movies only, Stills only, by Rating)

Slide Show

Image selection: All images, by Date, Folder, Movies, Stills

Playback time: 1/2/3/5/10/20 seconds

Repeat: On/Off

Background music: On/Off

Transition effect: Off, Slide in 1, Slide in 2, Fade 1, Fade 2, Fade 3

Histogram

Brightness: Yes

RGB: Yes

Highlight Alert

Yes

Image Erase/Protection

Erase: Single image, All images in folder, Checkmarked images, unprotected images

Protection: Single image, all images in folder, all images on card

Menu Categories

(1) Shooting menu (x4)

(2) Playback menu (x2)

(3) Setup menu (x3)

(4) Custom Functions menu

(5) My Menu

Firmware Update

Update possible by the user.

Computer

Hi-Speed USB

Other

Video output (PAL/ NTSC) (integrated with USB terminal), HDMI mini output (HDMI-CEC compatible), External microphone (3.5mm Stereo mini jack)

Canon Printers

Canon Compact Photo Printers and PIXMA Printers supporting PictBridge

PictBridge

Yes

Type

SD, SDHC or SDXC (UHS-I)card

PC & Macintosh

Windows XP inc. SP3 / Vista inc. SP2 (excl. Starter Edition) / 7 inc. SP1(excl. Starter Edition) / 8

OS X v10.6-10.8 (Intel processor required)

Browsing & Printing

ImageBrowser EX

Image Processing

Digital Photo Professional

Other

PhotoStitch, EOS Utility, Picture Style Editor

Batteries

1 x Rechargeable Li-ion Battery LP-E8

Battery Life

Approx. 440 (at 23°C, AE 50%, FE 50%) (5)

Approx. 400 (at 0°C, AE 50%, FE 50%)

Battery Indicator

4 levels

Power Saving

Power turns off after 30sec or 1, 2, 4, 8 or 15mins.

Power Supply & Battery Chargers

AC Adapter Kit ACK-E8, Battery charger LC-E8, LC-E8E

Body Materials

Stainless Steel and polycarbonate resin with glass fiber

Operating Environment

0 – 40 °C, 85% or less humidity

Dimensions (WxHxD)

133.1 x 99.8 x 78.8 mm

Weight (Body Only)

Approx. 580g (CIPA testing standard, including battery and memory card)

Viewfinder

Eyecup Ef, E-series Dioptric Adjustment Lens with Rubber Frame Ef, Eyepiece Extender EP-EX15II, Angle Finder C

Case

Semi-Hard Case EH22-L

Wireless File Transmitter

Compatible with Eye-Fi cards

Lenses

All EF and EF-S lenses

Flash

Canon Speedlites (90EX, 220EX, 270EX, 270EX II, 320EX, 420EX, 430EX, 430EX II, 550EX, 580EX, 580EX II, 600EX, 600EX-RT, Macro-Ring-Lite, MR-14EX, Macro Twin Lite MT-24EX, Speedlite Transmitter ST-E2, Speedlite Transmitter ST-E3-RT)

Battery Grip

BG-E8

Remote Controller/ Switch

Remote Switch RS-60E3, Remote Controller RC-6

Other

Hand Strap E2, GPS Receiver GP-E2
